商品详细介绍: 主要用途 Main Uses: 本机适用于制药及其它工业上的干物料、颗粒混合用。 This machine is applicable to the medicine of system, and other industries ascend of fuck the material grain mixs with to use. 主要特点 Main Properties: 本机混合筒结构独特,混合功率高,无死角,混合均匀。该机还可增加强制搅拌功能,对于较细的粉粒,凝块后或两种以上的粉状体,含有一定水份的物料均能混合。如对微量物相和的添加物也可达到混合效果(指添加量很少的配料混合)。 This machine has the special construction, high effection, no dead angle, mixture uniformity. The machine can also increase to mix blend the function compulsory. lt can mix thin powder and more than two form powders including the materials that contain water. lt can get the good result of admixture(mean that admixture additives).
型号 |
GHJ-100 |
GHJ-180 |
GHJ-300 |
GHJ-500 |
GHJ-1000 |
GHJ-1500 |
GHJ-2000 |
全容积m3 |
0.1 |
0.18 |
0.3 |
0.5 |
1.0 |
1.5 |
2.0 |
生产能力kg/次 |
30 |
60 |
100 |
160 |
300 |
500 |
650 |
进料时间min |
4-6 |
4-6 |
4-6 |
4-6 |
6-9 |
6-10 |
12-18 |
混合时间min |
12 |
6-10 |
6-10 |
6-10 |
6-10 |
6-10 |
6-10 |
筒体转速r/min |
12 |
12 |
12 |
12 |
12 |
12 |
12 |
电机功率kw |
1.1 |
1.1 |
1.5 |
2.2 |
4 |
4 |
7.5 |
回传总高度mm |
1200 |
1870 |
1870 |
2450 |
2940 |
2940 |
2940 |
外形尺寸mm |
1500*500*1300 |
1780*680*1700 |
1880*680*1700 |
2500*1350*2450 |
2500*1350*2450 |
3055*1650*2980 |
3340*1650*2980 |
整机重量kg |
150 |
290 |
300 |
550 |
850 |
1020 |
2040 |
|
